Technical Parameter

Model                                                2ZG-6D(PH600)                                    2ZG-8(PH800)
Engine model                               JF620      GX620KI                                 JD902   3TNM72
Engine type                     air-cool,4-stroke,ohv,twin cylinder        water-cooled,3 cylinder,vertical
Max.Output(hp/rpm)                           13.5/3600                                               16.2/3200
Planting rows                                              6                                                               8
Row interval(mm)                                                                      300
Hill-to-hill spacing(mm)       260/223/187/158/133/122                   260/220/180/160/140/120
Planting depth(mm)                                                         8~19(12 level)

Planting speed(km/h)                           ≤5.04                                                     ≤6.48
Front wheel type                                                                     solid tyre
Front wheel diameter(mm)                                                    ∮650
Rear wheel type                                                                rubber lug wheel
Rear wheel diameter(mm)                                                     ∮900
Dimensions(L×W×H)(mm)      3000×2080×1520                             3350×2220×2000
Net weight(kg)                                            620                                                           850
